JIS20K flange swing check valve is manufactured according to Japanese JIS standards. The main materials are stainless steel SCS13/SCS14 and carbon steel SCPH2. The pressure rating of the valve is represented by K.
The installation position of JIS 20K swing check valve flange end swing check valve is not limited. Usually installed in horizontal pipelines, but it can also be installed in vertical pipelines. Or tilt the pipeline The disc swing check valve rotates around the shaft, and its fluid resistance is generally smaller than that of the lift check valve, making it suitable for larger diameter applications.
flange connection JIS 20K swing check valve body material: SCPH2, SCS13, SCS14 nuclear power source: 50A-500A design standard: JIS B2071, ASME B16.34 face-to-face: JIS B2002 flange standard: JIS B2220 inspection and testing: JIS B2003 type: flange valve cover
